High Efficiency
Compression Driver

Neodymium Motor

· High sensitivity (107 dB/SPL)
· Extended frequency range (2,.5 -18 kHz)
· Aluminium diaphragm
· Neodymium magnet
· Aluminium front cover
· Designed for the high frequencies reproduction

Specifiche Tecniche
Impedenza: 4 Ohm
Sensibilità: 107 dB 1w @ 1m
Gamma di frequenza: 2,5 - 18 kHz
Taglio crossover consigliato: 3,7 kHz
Diametro bobina: 25 mm
Magnete: Neodimio
Bobina: Alluminio
Diaframma: Alluminio

TECHNICAL SPECIFICATIONS
Nominal impedance: 4 Ohm
Sensitivity: 107 dB 1w @ 1m
Frequency range: 2,5 - 18 kHz
Recommended Crossover: 3,7 kHz
Voice coil diameter: 1"
Magnet: Neodymium
Winding material: Aluminum
Diaphragm material: Aluminium

Specifiche di installazione
Scarica disegno tecnico
Diametro esterno: 58.5 mm
Altezza totale: 72.5 mm
Diametro fissaggio: 50 mm
Peso: 0,5 kg

Mounting SPECIFICATIONS
Download technical drawing
Overall diameter: 58.5 mm
Depth: 72.5 mm
Bolt circle diameter: 50 mm
Weight: 0,5 kg
